The short answer
If you removed the bar-end weight on your Moto Guzzi and found a solid, welded piece with a threaded hole instead of a hollow tube — congratulations, nothing is wrong with your bike.
That welded insert is the mounting point. It's an M6 threaded boss that Moto Guzzi welds into the factory handlebar to hold the bar-end weights. Our Moto Guzzi bar-end mirrors are designed to bolt directly into that same M6 thread. No drilling, no expander wedges, no handlebar swap.
Why riders get confused
Most universal bar-end mirrors are built for hollow handlebars: they use a rubber or aluminum expander that slides inside the open tube and clamps outward. When a Guzzi owner unscrews the factory weight and sees a solid welded plug, the expander-type hardware obviously won't fit — and it looks like bar-end mirrors are impossible on this bike.
They're not. You just need hardware made for the threaded bar, not the hollow bar.
Installation in three steps
- Remove the factory bar-end weight. One bolt per side. Tip: use a well-fitting hex key and steady pressure — the factory thread-locker can be stiff, and a worn key can round or snap the bolt head. A short burst of heat from a hair dryer helps loosen the thread-locker.
- Place the supplied spacer against the bar end.
- Bolt the mirror on with the supplied M6 bolt into the factory insert. Torque snugly, adjust the ball joints, done.
Total time: about 10 minutes for the pair. Our Stark bar-end mirrors for Moto Guzzi ship with the correct M6 bolt and spacer for this exact setup.
Which Moto Guzzi models does this fit?
Any Moto Guzzi with the factory M6-threaded handlebar, including:
- V7 / V7 II / V7 III (Stone, Special, Racer, Rough, Milano, Carbon, Anniversario) / V7 850 E5
- V9 Bobber, V9 Roamer
- V85 TT (all versions), V85 Strada
- V100 Mandello / Mandello S
- Audace, MGX-21, Eldorado, California 1400
- Griso and Stelvio 1200 (OEM thread adapter #883134 required)
Important: this fitment is for the original factory handlebar only. If your bike has an aftermarket bar, choose our hollow-bar (expander) hardware instead, matched to your bar's inner diameter.
Not sure which handlebar you have? Send us a photo of the bar end with the weight removed — we'll confirm fitment before you order.
"But Guzzis vibrate — will the mirror stay clear?"
Fair question: the 90° V-twin has character. Two things matter:
- Keeping the factory bar-end weights' job covered. Bolting a mirror onto the bar end replaces the weight with the mirror's own mass, which continues to damp bar resonance. Our Stark for Moto Guzzi weighs 702 g per pair — comparable to typical bar-end weights.
- Rigid, play-free mounting. A mirror that bolts solidly into the welded insert shakes less than one hanging off a loose expander.
Real-world result: riders report a clear image at highway speed on V7s. For the physics behind it, see our guides Why Motorcycle Mirrors Vibrate and How to Fix Motorcycle Mirror Vibration.
FAQ
Q: Do I need to remove the grips or controls?
No. Only the bar-end weight comes off.
Q: Will this fit my aftermarket handlebar?
No — the M6 hardware is for the factory welded insert only. Use our hollow-bar hardware for aftermarket bars.
Q: My bar-end bolt is stuck / the head stripped. Now what?
Apply heat to soften the thread-locker and use a quality hex bit. If the head is already stripped, a bolt extractor works on the factory bolt without harming the welded insert.
Q: Is this the same question riders ask on forums?
Yes — this exact "welded plug" question comes up on Reddit's r/MotoGuzzi, GuzziTech, and European Guzzi forums. The answer is always the same: the plug is the thread, and threaded-type hardware bolts straight in.
